Summary

• Summer Break

• Syllabus overview
• books & supplies
• course goals
• assignments & grading
• Canvas


• About the professor




• How to learn physics
• learning athletics
• learning music
• interactive lectures
• deeper thinking, recognizing patterns
• curiosity



• How to fail at college
• Mistake #1: Poor metacognition
• Mistake #2: Ineffective orienting tasks
• Mistake #3: Unhelpful study strategies
• Mistake #4: Taking poor notes
• Mistake #5: Bad recovery plan
• Videos by Dr. Stephen Chew, cognitive psychologist, Samford University




• How to succeed in college
• Set a GPA goal
• Treat college like an 8 to 5 job
• Attend class
• Keep up
• Strive for good sleep
• Relate to your professors
• Be a "well-rounded square"




---

Chapter 22

---




• Electric charges
• origin & types
• conductors
• insulators
• transferring charge
Example #1
Example #2


• Fundamental physical constants NIST CODATA 2018
• web site
• wall chart




• Lecture learning outcomes
  A student who masters the topics in this lecture will be able to:
• explain the characteristics of electric charges in terms of sign and magnitude
• describe the principle of charge conservation
• correctly use the Coulomb unit (C) and the fundamental charge quantity e


• Course learning outcomes
Upon successfully completing Physics 250, a student will be able to:
• explain the fundamental concepts of electricity, magnetism, circuits, and optics
• use graphs, algebra, and calculus to explain measurements and make predictions
• describe the usefulness and limitations of problem-solving methods for realistic examples


• GEP natural science learning outcomes
Upon successfully completing Physics 250, a student will be able to:
• explain major concepts, methods, or theories used in the natural sciences to investigate the physical world
• interpret information, solve problems, and make decisions by applying natural science concepts, methods, and quantitative techniques
• describe the relevance of aspects of the natural sciences to their lives and society



• Practice:
  Try these additional examples
Example #3

Example #4



• Prepare:
  Read textbook sections 22.1 through 22.4 before the next lecture (I know that's a lot. We will typically cover only a few sections per lecture.)

---

Knight2 stt26.2
Rank in order, from most positive to most negative, the charges q_a to q_e of these five systems:

1. proton
2. electron
3. 17 protons and 19 electrons
4. 1,000,000 protons and 1,000,000 electrons
5. glass ball that's missing 3 electrons

A. a > b > c > d > e
B. c > b > a > e > d
C. b > e > c > d > a
D. e > a > d > b > c
Answer















kw4
When a neutral water molecule disassociates into an H⁺ ion and an OH⁻ ion, what can we say about the amounts of charge on the two ions?
A. They have the same amount of charge.
B. The OH⁻ has more negative charge
C. The H⁺ has more positive charge
D. Need to measure the charges.
Answer















klm
A negatively charged plastic rod attracts bits of paper. We can conclude the paper bits are
A. positively charged
B. negatively charged
C. electrically neutral
D. either A or C
E. It is impossible to draw any conclusions about the paper.
Answer















Knight2 26.stt.1
To determine if an object has positive charge, you need to
A. see if the object attracts a negatively charged object.
B. see if the object repels a positively charged object.
C. Do both A and B.
D. Do either A or B.
Answer





























1. proton = +e
2. electron = −e
3. 17 protons and 19 electrons = −2e
4. 1,000,000 protons and 1,000,000 electrons = 0
5. glass ball that's missing 3 electrons = +3e

By comparing the net charge values we arrive at the ranking:
D. e > a > d > b > c

























A. They have the same amount of charge.
This must be true because the sum of the two charges must be zero in order for the molecule to have been electrically neutral before it disassociated.
























D. either A or C
The bits of paper can be attracted to the negatively charged rod if they are either positively charged or neutral (in which case the attraction is caused by charge polarization). We can only rule out answer B because if the paper bits were negatively charged they would be repelled by the negatively charged rod.
























B. see if the object repels a positively charged object.
Attraction to a negative charge is not helpful for determining whether an object is positively charged because neutral objects (like bits of paper) are also attracted to a positively charged object. But repulsion by a known positive charge is definitive proof the object is positively charged.
